LGMC HD16 Dozer With Weichai WD10G178E25 Engine Planetary Gear Type
Power-Shift Forced Lubrication
Product Description:
· Place of Origin: China
· Model Number:HD16
· Name:Construction Bulldozer
· Warranty: 3 Months
· Delivery: 10-15 Working Days
· Stock quantity: available
Packaging & Delivery :
Packaging Details: Container
Port: QINGDAO
PAYMENT:30% AS DEPAOISTS ,THE BALANCE SHOULD PAID BEFORE SHIPMENT.
Bulldozer is a kind of multi-purpose self-moving earthwork
construction machinery, which can shovel and transport soil. For
example, in the road construction,bulldozer can complete the
treatment of subgrade foundation, the lateral filling height of
embankment is not more than1m, the subgrade excavation and filling
project along the road center line to shovel and transport soil,
and the subgrade with half embankment and half cutting along the
mountain. In addition, bulldozer can also be used to level the
site, pile up loose materials, remove obstacles in the operating
area, and so on.
| Overall | Dimension | 5140×3388×3032 mm |
| Operating Weight | 17000 kg |
| ENGINE | Model | Weichai WD10G178E25 |
| Type | Water-cooled, in-line, 4-stroke,direct injection |
| Number of Cylinders | 6 |
| Bore × Stroke | Φ126×130 mm |
| Piston Displacement | 9.726 L |
| Rated Power | 131 KW (178HP) @1850 rpm |
| Max Torque | 765 N·m @1300 rpm |
| Fuel Consumption | 214 g/kW·h |
| TRANSMISSION | Torque Converter | 3-element, 1 stage, 1 phase |
| Transmission | Planetary gear type, power-shift, forced lubrication |
| Central Drive Shaft | Spiral bevel gear, single-stage speed reduction, splash lubrication |
| Steering clutch | Wet, multi-disc, spring loaded, hydraulically separated, hydraulic
control |
| Steering brake | Wet type,floating band structure,foot brake with hydraulic booster |
| Final drive | 2-stage speed reduction of spur gear, splash lubrication |
| TRAVEL SPEED | Gear | 1st | 2nd | 3rd |
| Forward | 0~3.29 km/h | 0~5.82 km/h | 0~9.63 km/h |
| Reverse | 0~4.28 km/h | 0~7.59 km/h | 0~12.53 km/h |
UNDERCARRIAGE SYSTEM | Type | Sprayed beam, suspended structure of equalizer |
| No. of Carrier Rollers | 2 each side |
| No. of Track Rollers | 6 each side |
| No. of Track Shoes | 37 each side |
| Track Shoe type | Single Grouser |
| Width of Track shoe | 510 mm |
| Pitch | 203.2 mm |
| Track Gauge | 1880 mm |
| Ground Preasure | 0.067 Mpa |
| HYDRAULIC SYSTEM | Max Pressure | 14 Mpa |
| Pump Type | Gear Pump |
| Displacement | 243 L/Min |
| Bore of Working Cylinder | 110 mm × 2 |
BLADE | Blade Type | Straight-tilt Blade | Angle Blade | Semi-U-blade |
| Blade Capacity | 4.5 m³ | 4.3 m³ | 5 m³ |
| Blade Width | 3388 mm | 3970 mm | 3556 mm |
| Blade Height | 1150 mm | 1040 mm | 1120 mm |
| Max Drop Below Ground | 540 mm | 540 mm | 530 mm |
| MaxTilt Adjustment | 400 mm | – | 400 mm |
| THREE SHANK RIPPER | Max digging depth | 572 mm |
| Max lift above ground | 592 mm |
| Weight of 3-shank ripper | 1667 kg |
Our advantages :
1. We can help buyers design specific products or produce products
according to buyers' design.
2. Small order acceptable.
3. Competitive price be offered.
4. Inquiry or question be answered within 12 hours.
5. Best possible after-sales service.
6. We can print logo according to buyers' requirement.
7. Stock an extensive range of spare parts.
8. Favourable geographical location.
9. Flexible pricing, offers discount and deferred payment for
wholesale buyers.
10. Timely delivery.
FAQ:
Q1. Could you custom products?
A: We can manufacture it according to your drawings or samples.
Q2. What's your payment terms.
A: By T/T or Western Union, 100% in advance. ( large orders can be
negociated)
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: 1-3 working days in general, and 7-10 days for large orders.
Q5. How can you guarantee the quality?
A: One year's warranty against B/L date.If You meet with quality
problem, we promise to responsible for it.
Q6: Can we buy 1 pc of each item for quality testing?
A: Yes, we understand quality test is important and we are glad to
send 1pc for quality testing.
